RYK 420

Radial Saw Machine

RYK 420 Radial Saw Machine is designed for the strait or angular cutting operations of the large size of materials made of PVC, aluminium, brass, teflon, bakelite, wood and other non-ferrous metals . RYK 420 allows straight and angular cuttings by means of the pivoting and tilting head.

Optional Accessories

Saw blades for aluminum or PVC
Spray saw blade lubrication system
Motor break unit working with button off
Laser marking indicating the cutting line
Digital display for ease adjustment of pivoting angle
Hydraulic control unit for saw head feed rate
Miter for longitudinal cutting operations
DKN 302
DKN 452
DKN 602 and MKN 301 conveyors

General Features

Performing of different cutting operations are possible by means of the pivoting and tilting features
Powerful cutting operations by means of the 2.2 kW
3000 r.p.m motor
Smooth movement
high precision and great sensitivity provided with gas spring
linear bearings and ergonomic handle
2 x pneumatic vertical clamps & extension pieces
Cast iron construction of the body that is strong and lasting
Robust mechanical construction enables the ease of adjustment for the requested cutting angles
Equipped with saw blade diameter 420 mm for timber cutting
Location points at 150-22
50-300-450-600-900 both left and right
Pivoting range from 15° right to 15° left infinitely adjustable
Tilting range from 90° to 45° left
